Coin-Up Pinball

Data East / Sega Pinball CPU / MPU Board 520-5003-00 / 520-5003-01 / 520-5003-02 / 520-5003-03

Data East / Sega Pinball CPU / MPU Board 520-5003-00 / 520-5003-01 / 520-5003-02 / 520-5003-03

Regular price $849.00 AUD
Regular price Sale price $849.00 AUD
Sale Sold out

This Product is Available from Our Authorised Retailers

Retrocity

RTTB

Retrocity
Location: Australia
Range: Pinball
Ships: Worldwide
Website: Retrocity.com.au
RTBB
Location: Australia
Range: Pinball
Ships: Worldwide
Website: rtbb.com.au
Data East / Sega Pinball CPU / MPU Board 520-5003-00 / 520-5003-01 / 520-5003-02 / 520-5003-03

Plug and Play direct 1:1 replacement with all features from the original.

Replaces Data East 520-5003-00/01/02/03

- NVRAM Included (No Need For Batteries)
- High Quality Components
We only use genuine components from reputable companies,
(ST, Onsemi, Molex, Nichicon, TE Connectivity, Vishay, Yageo etc)
- Every Chip Socketed for Easy Repair (All sockets are TE Connectivity)
- Shrouded IDC Ribbon Cable Headers
- Upgraded Williams style mounting keyholes for easy install/removal
- Upgraded Button Cell Battery Socket with Original AA Unpopulated Footprint
- Upgraded Q64-Q71 Mosfets to eliminate heat - board has been thermal tested and runs extremely cool.
(Original transistor circuitry remains and can be used if desired)
- Resistor vent holes with isolated plains added under R55-R62
- Jumper pins added for quick game compatibility set-up
- Genuine/Authentic WDC 6821 PIA’s
- Original socketed Japan FRL relay for easy removal
- 2 layer ground plains added top and bottom for solid ground reliability
- True to Original (Original Schematics Can Be Used)
- Supports Every Single Game as the Original
- 12 Months Local Warranty
- Designed & Assembled in Australia

NVRAM & CPU are included
Game ROM Not Included

Game Compatibility:

Back to the Future
Batman
Batman Forever
Baywatch
Checkpoint
Frankenstein
Guns N' Roses
Hook
Jurassic Park
Laser War
Last Action Hero
Lethal Weapon 3
Maverick
Monday Night Football
Phanton of the Opera
Playboy 35th Anniversary
Robocop
Rocky & Bullwinkle
Secret Service
Simpsons
Star Trek 25th Anniversary
Star Wars
Tales from the Crypt
Teenage Mutant Ninja Turtles
Time Machine
Tommy
Torpedo Alley
WWF Royal Rumble
